Decoder

Video decoder :
• Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders• Support smulti-video decoder up to 4x1080P@60fps
• Supports multiple “secured” video decoding sessions and simultaneous    decoding and encoding
• Video/Picture Decoding• VP9 Profile-2 up to 8Kx4K@24 fps• AVS2-P2 Profile up to 8Kx4K@24 fps• 264.H AVC 1.HP@L5 up to 4Kx2K@60fps• MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)• WMV/VC-1 SP/MP/AP up to 1080P@60fps
• AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps• MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
• MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
• RealVideo 8/9/10 up to 1080P@60fps• Multiple language and multiple format sub-title video support • MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
• Supports JPEG thumbnail, scaling, rotation and transition effects
• Supports *..mkv,*mpg,.wmv,* *mpeg,. *dat,. *avi,. *mov,. *iso,. *mp4,. *rm. and *jpg. file formats

Audio decoder :
• Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1
down-mixing
• Low-power VAD
• Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output • 3 built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x 32bits x 16ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 16ch
• Digital microphone PDM input with programmable CIC, LPF & HPF, supports
   up to 8 DMICs
• Built-in stereo audio DAC
•  Supports concurrent dual audio stereo channel output with combination of  analog+PCM or  I2S+PCM
